Epica Human Health - Advanced Mobile Point-of-Care Imaging Platforms

See Factor CT3™

The World’s First Ultra-High Resolution, Mobile, Multi-Modality Bedside Imaging Platform

Three Modalities, One Robust Platform

Turn almost any space into an imaging room, supporting multi-use cases in Acute Care, ICU, ER, OR, IR Suite, ASCs, Outpatient, Physicians’ office, and more.

Epica’s all new See Factor CT3™ , a High Resolution, Mobile, Multi-Modality Point-of-Care Imaging Platform is designed to deliver non-interpolated, isotropic volumetric DICOM data.

SeeFactorCT3™ offers high spatial resolution and low noise in its CT images that can be displayed within minutes of acquisition in the onboard DICOM viewer.

FDA 510(K) Cleared for use in human diagnostic imaging

Mobile & Compact platform: suitable for ICU, ER/Trauma, OR, and Imaging Rooms

Mobility

Turn any room into an imaging room with See Factor CT3™’ compact, mobile design. Easily moves through standard doors by one technician.

Multi-Modality

3-in-1 imaging platform that provides superior 3D diagnostic imaging, digital radiography and fluoroscopy capabilities.

100% Real Data

Non-interpolated (gapless, 100% real) image data delivering extraordinary isotropic image resolution as fine as 0.2mm in soft & hard tissue.

HDVI: A New Imaging Standard

HDVI (High Definition Volumetric Imaging) is a new hybrid technology in CT that provides unprecedented diagnostic and interventional information for clinicians.

Epica's See Factor CT3™ is a multi-modality, mobile imaging platform that utilizes HDVI technology to deliver a 3D map of densities with spatial resolution that is the same in all three dimensions.

Three Modalities, One Robust Platform

HDVI Imaging

HDVI (High Definition Volumetric Imaging) is a new hybrid technology in CT that provides unprecedented diagnostic information for clinicians.

Fluoroscopy

High-resolution images, auto-brightness/contrast, and frame rates from 1-30 fps. Any orientation of the patient may be viewed and the gantry can move over the patient during a study.

Digital Radiography

Built-in Digital Radiography system that can be used in a single shot or scanning mode to allow a complete scan in a single radio-graph. Images may be taken at any angle.

FDA 510(k) Recently Expanded Applications Include

Height: 71 inches

Width: 35.7 inches

Length: 88 inches

Weight: 1689.47 Ibs

Power: 230V, 30 amp, Single Phase

HDVI (CT) Field of View: Up to 35cm radius x 1.08m length
HDVI (CT) Resolution: 0.1mm - 0.6mm in 3 dimensions with true isotropic voxels
HDVI single data sets output – no need for reprocessing multiple planes
Fluoroscopy (full-featured): 1-30 fps, high resolution with auto-brightness, 3-dimensional orientation adjustment, DSA, Road-mapping, Tip-Tracking, Auto-Collimation
Digital Radiography: Scan Speed: 4-24 seconds for first 15cm, +13-30 seconds for each additional 15cm
Seefactor-mobile-bedside-imaging-platform

FDA 510(k) approved for these uses:

Skull

Oromaxillofacial Bones

Cervical Spine

Thoracic Spine

Lumbar Spine

Hips

Knees

Ankles/Feet

Shoulders

Elbows

Hand/Wrist

We are working toward interventional (HDVI CT + Fluoro) including, but not limited to:

✓ Precision guided injections
✓ Biopsies
✓ Tumor ablation (this includes bone)
✓ Vascular (Peripheral)
✓ Arthrography

✓Basic image guided tube placement and injection

Education & Training

Every product installation is supported by EPICA's in-house, US-Based support team. We provide on-site as well as remote training sessions to ensure your team is equipped with the knowledge required to operate See Factor CT3™. Ongoing training is provided through EpiCare which is included in the first year of product ownership.

In addition, Epica Human Health offers a variety of hands-on, interactive educational programs to promote information sharing amongst device users and to provide regular updates on product enhancements as well as best practices.

All EPICA clients are automatically enrolled in EPICA Education program and can benefit from our educational resources which include regular webinars, case libraries, and user forums.

Service & Support

Backed by EpiCare warranty, See Factor CT3™ comes with a one-year manufacturer's warranty. Additional warranty can be obtained through our EpiCare program.

EpiCare is a comprehensive support plan that includes:

- Access to 24/7 U.S. based support

- Software/firmware updates

- Ongoing training and support

Please contact us for additional information about our warranty program and details.

Get the See Factor CT3™ Spec Sheet

Mobile (motorized), can be moved by one person35.7 inches wide , easily maneuverable through standard sized doorsDetector & amp; source positioned outside the bore to provide more room for patient-physician interaction

Flexible positioning for table, chair or bedpolyurethane Shockproof protection

Control panel w/adjustable display and keyboardMobile (motorized), Can be easily moved to patient side24.60"(62.5 cm) BoreHigh Definition Diagnostic Imaging, Digital Radiography, and Fluoroscopy onboardGantry extends forward and indexes over the table

EpiCare™

At EPICA, we strive to provide our clients with advanced, high quality medical imaging solutions. We also take pride in our dedication to supporting our clients at each and every step of the process: from the fisrt day of install to continuing education and system upgrades.

Our imaging technology and devices are backed by EpiCare warranty. EpiCare is a comprehensive support plan that includes:

- Access to 24/7 U.S. based support

- Software/firmware updates

- Ongoing training and support

- Co-marketing & more

Please contact us to learn more about our commitment to quality and care through EpiCare.
